We see the following noise on all output channels of both our 2 Fastino boards, see purple trace (channel 3):

${fastino_noise_2}$

Has anybody else seen such noise on Fastino outputs?

See below for more photos of the noise and for details about our setup.

Note: Ignore the weird shape of the green trace (channel 4), the Urukul gets into trouble at f=350 MHz, att=10 dB, ampl=1.0. Similar problems appear at 100 MHz. Nothing strange, I think. The cyan trace (channel 2) looks ok because it's at 250 MHz.

Our setup:

1x Kasli SoC v1.1.1 master connected to 12x DIO_SMA v.1.4.1
1x Kasli SoC v1.1.1 satellite connected to 2x Fastino v1.2.1
1x Kasli SoC v1.1.1 satellite connected to 1x Clocker v1.1rc2 and 6x Urukul v1.5.4
artiq-zynq commit a0281e498927d5c8467dd18f28aa497cb75150fd: most recent on branch master right now (January 2025)
artiq commit 63db4af1fcd9c5cb305a3eee2c0f82bf3de95563: most recent on branch master right now (January 2025)

${setup_with_fastino_noise}$

More photos of the noise on the Fastino output; it looks the same on all channels of both our Fastino boards:

${fastino_noise_1}$

${fastino_noise_3}$

${fastino_noise_4}$

${fastino_noise_5}$

Code to reproduce:

Requires pip install -e . of tiny custom package artiq-testing!

from artiq.experiment import EnvExperiment, kernel, rpc
from artiq.language.types import TNone, TBool, TInt32, TStr, TList
from artiq.language.units import ns, us, ms, s, MHz
from artiq.coredevice.ad9910 import PHASE_MODE_CONTINUOUS

import artiq_testing as at

class TestSatellites(EnvExperiment):

    @rpc
    def build(self) -> TNone:
        self.t0 = time.time()
        self.setattr_device("core") # artiq.coredevice.core.Core
        # ---- LED-related channels ----
        for i in range(at.NUMBER_OF_LED_CHANNELS):
            self.setattr_device(f"led{i}") # artiq.coredevice.ttl.TTLOut
        self.led_ch_list = [getattr(self, f"led{i}") for i in range(at.NUMBER_OF_LED_CHANNELS)]
        # ---- TTL-related channels ----
        self.setattr_device("i2c_switch0") # artiq.coredevice.i2c.I2CSwitch
        self.setattr_device("i2c_switch1") # artiq.coredevice.i2c.I2CSwitch
        for i in range(at.NUMBER_OF_TTL_CHANNELS):
            self.setattr_device(f"ttl{i}")
        self.ttl_ch_list = [getattr(self, f"ttl{i}") for i in range(at.NUMBER_OF_TTL_CHANNELS)]
        # ---- AO-related channels ----
        for i in range(at.NUMBER_OF_FASTINO_BOARDS):
            self.setattr_device(f"fastino{i}") # artiq.coredevice.fastino.Fastino
        self.ao_ch_list = [getattr(self, f"fastino{i}") for i in range(at.NUMBER_OF_FASTINO_BOARDS)]
        # ---- DDS-related channels ----
        for i in range(at.NUMBER_OF_URUKUL_BOARDS):
            self.setattr_device(f"urukul{i}_cpld") # artiq.coredevice.urukul.CPLD
            for j in range(4):
                self.setattr_device(f"urukul{i}_ch{j}")     # artiq.coredevice.ad9910.AD9910
                self.setattr_device(f"ttl_urukul{i}_sw{j}") # artiq.coredevice.ttl.TTLOut
        self.urukul_cpld_list = [getattr(self, f"urukul{i}_cpld") for i in range(at.NUMBER_OF_URUKUL_BOARDS)]
        self.dds_ch_list = [getattr(self, f"urukul{i}_ch{j}") for i in range(at.NUMBER_OF_URUKUL_BOARDS) for j in range(4)]
        self.dds_ttl_list = [getattr(self, f"ttl_urukul{i}_sw{j}") for i in range(at.NUMBER_OF_URUKUL_BOARDS) for j in range(4)]
        # ---- load configurations ----
        # [b00000000, b00001111, b11110000, ...] for every DIO_SMA board
        # [2, 0 , 2, 2, ...] for every TTL channel
        (self.dio_sma_board_directions_binary, self.ttl_channel_is_output) = at.get_ttl_directions(
            banks_with_inputs = [], # 0-23
            verbose           = False,
        )
        self.t1 = time.time()

    @kernel
    def init(self) -> TNone:
        at.set_ttl_directions(
            core                    = self.core,
            i2c_switches            = [self.i2c_switch0, self.i2c_switch1],
            board_directions_binary = self.dio_sma_board_directions_binary,
            ttl_ch_list             = self.ttl_ch_list,
            channel_is_output       = self.ttl_channel_is_output,
            verbose                 = False,
        )
        for ttl_ch in self.ttl_ch_list:
            delay(8*ns)
            ttl_ch.off()
        print("INFO: DIO init() complete")
        self.core.break_realtime()
        for fastino in self.ao_ch_list:
            fastino.init()
        for fastino in self.ao_ch_list:
            for ch in range(32):
                delay(8*ns)
                fastino.set_dac(ch, 0.0)
        print("INFO: Fastino init() complete")
        self.core.break_realtime()
        for urukul_cpld in self.urukul_cpld_list:
            urukul_cpld.init()
        for dds_ch in self.dds_ch_list:
            dds_ch.init()
        for sw in self.dds_ttl_list:
            delay(8*ns)
            sw.off()
        for dds_ch in self.dds_ch_list:
            delay(8*ns)
            dds_ch.set_phase_mode(PHASE_MODE_CONTINUOUS)
            dds_ch.set_att(10.0)
        print("INFO: Urukul init() complete")
        self.core.break_realtime()

    @kernel
    def run(self) -> TNone:
        self.core.reset()
        self.init()
        delay(1*ms)
        self.urukul0_ch0.set(
            frequency = 250*MHz,
            phase     = 0.0,
            amplitude = 1.0,
            phase_mode = PHASE_MODE_CONTINUOUS,
        )
        self.urukul4_ch3.set(
            frequency = 350*MHz,
            phase     = 0.0,
            amplitude = 1.0,
            phase_mode = PHASE_MODE_CONTINUOUS,
        )
        delay(1*us)
        self.ttl0.on()
        self.ttl_urukul0_sw0.on()
        self.fastino0.set_dac(22, 0.6)
        self.fastino1.set_dac(28, 0.6)
        delay(1*us)
        self.ttl_urukul0_sw0.off()
        delay(2*us)
        self.ttl_urukul4_sw3.on()
        self.ttl0.off()
        delay(1*us)
        self.ttl_urukul4_sw3.off()

If the above link to artiq-testing is broken, just copy from here:

from artiq.coredevice.kasli_i2c import port_mapping

# Maps Kasli EEM port indices that are visible on the PCB
# to actual electrical port(?) indices that need to be passed to the FPGA.
KASLI_I2C_BOARD_TO_PORT_MAPPING = [port%8 for port in port_mapping.values()]

# Maps our own enumeration convention of DIO_SMA boards' banks
# to actual electrical port(?) indices that need to be passed to the FPGA.
# so [7, 5, 4, ...] becomes [7, 7, 5, 5, 4, 4, ...]
KASLI_I2C_DIO_SMA_BANK_TO_PORT_MAPPING = [port%8 for port in KASLI_I2C_BOARD_TO_PORT_MAPPING for i in range(2)]

# for `artiq.coredevice.i2c.i2c_write_byte(busno, busaddr, data, ack=True)`
# and `artiq.coredevice.i2c.i2c_read_byte(busno, busaddr)`
DIO_SMA_BUS_NUMBER = 0
DIO_SMA_BUS_ADDRESS = 0x7c # = 124 (decimal) or 01111100 (binary)

NUMBER_OF_KASLIS = 3
NUMBER_OF_DIO_SMA_BOARDS = 12
NUMBER_OF_FASTINO_BOARDS = 2
NUMBER_OF_URUKUL_BOARDS = 5 # is actually 6 but one board is broken, see https://forum.m-labs.hk/d/877-urukul-v154-ld5-ld6-ld8-and-ld2-remain-dark-ad9910init-crashes
NUMBER_OF_LED_CHANNELS = 2 * NUMBER_OF_KASLIS
NUMBER_OF_TTL_CHANNELS = 8 * NUMBER_OF_DIO_SMA_BOARDS
NUMBER_OF_TTL_BANKS = 2 * NUMBER_OF_DIO_SMA_BOARDS
NUMBER_OF_ANALOG_CHANNELS = 32 * NUMBER_OF_FASTINO_BOARDS
NUMBER_OF_DDS_CHANNELS = 4 * NUMBER_OF_URUKUL_BOARDS

and

from artiq.experiment import rpc
from artiq.language.types import TInt32, TStr

@rpc
def get_type(
    obj,
) -> TStr:
    return str(type(obj))

@rpc
def to_binary(
    number : TInt32,
) -> TStr:
    _bin = "{0:b}".format(number)
    return "0"*(8-len(_bin)) + _bin

@rpc
def prepend_zeros(
    number       : TInt32,
    total_digits : TInt32,
) -> TStr:
    return "0" * (total_digits - len(str(number))) + str(number)

@rpc
def prepend_characters(
    string       : TStr,
    total_digits : TInt32,
    character    : TStr,
) -> TStr:
    return character * (total_digits - len(string)) + string

and

from artiq.experiment import kernel, rpc, host_only
from artiq.language.types import TNone, TBool, TInt32, TList, TTuple
from artiq.language.units import ns, us, ms, s
from artiq.coredevice.i2c import i2c_write_byte, i2c_read_byte

from .console_outputs import get_type, to_binary, prepend_zeros, prepend_characters
from .constants import *

@rpc
def get_ttl_directions(
    banks_with_inputs  : TList(TInt32), # indices of TTL banks, e.g. [3,6,8]
    verbose            : TBool = False,
) -> TTuple([TList(TInt32), TList(TInt32)]):
    bank_directions = {bank : "output" for bank in range(NUMBER_OF_TTL_BANKS)}
    for bank in banks_with_inputs:
        bank_directions[bank] = "input"
    # convert direction data to 2 useful formats
    channel_is_output = [
        2*int(bank_directions[bank] == "output") \
        for bank in range(NUMBER_OF_TTL_BANKS) \
        for ttl_channel_in_bank in range(4)
    ]
    bank_upper = (1 << 4) - 1 # = 0x0f = b00001111
    bank_lower = bank_upper << 4 # = 0xf0 = b11110000
    board_directions_binary = [
        int((bank_upper * (bank_directions[bank] == "input")) | (bank_lower * (bank_directions[bank + 1] == "input"))) \
        for bank in range(0, NUMBER_OF_TTL_BANKS, 2)
    ]
    if verbose:
        for board in range(NUMBER_OF_DIO_SMA_BOARDS):
            print(
                "board", prepend_zeros(board, 2), "|",
                "i2c_addr", KASLI_I2C_BOARD_TO_PORT_MAPPING[board], "|",
                "new_dir", to_binary(board_directions_binary[board]),
                "(IO0-4", prepend_characters(
                    string       = bank_directions[2*board],
                    total_digits = 6,
                    character    = " ",
                ) + ", IO5-8", prepend_characters(
                    string       = bank_directions[2*board+1],
                    total_digits = 6,
                    character    = " ",
                ) + ")"
            )
    # [b00000000, b00001111, b00000000, ...] for every DIO_SMA board
    # [2, 0 , 2, 2, ...] for every TTL channel
    return (board_directions_binary, channel_is_output)

@kernel
def set_ttl_directions(
    core,
    i2c_switches,
    board_directions_binary : TList(TInt32),
    ttl_ch_list,
    channel_is_output       : TList(TInt32),
    verbose                 : TBool = False, # print to console
) -> TNone:
    for board in range(NUMBER_OF_DIO_SMA_BOARDS):
        if board < 8:
            sw = i2c_switches[0]
        else:
            sw = i2c_switches[1]
        i2c_addr = KASLI_I2C_BOARD_TO_PORT_MAPPING[board]
        sw.set(
            channel = i2c_addr,
        )
        i2c_write_byte(
            busno   = DIO_SMA_BUS_NUMBER,
            busaddr = DIO_SMA_BUS_ADDRESS,
            data    = board_directions_binary[board],
        )
        sw.unset()
        if verbose:
            print(
                "board", prepend_zeros(board, 2), "|",
                "i2c_addr", i2c_addr, "|",
                "new_dir", to_binary(board_directions_binary[board])
            )
    core.break_realtime()
    for channel_id in range(NUMBER_OF_TTL_CHANNELS):
        if channel_is_output[channel_id] > 1:
            ttl_ch_list[channel_id].output()
        else:
            ttl_ch_list[channel_id].input()
        if channel_id % 10 == 0:
            delay(1*us)

@kernel
def set_ttl_bank_to_output(
    i2c_switches,
    bank    : TInt32,
    verbose : TBool  = False,
    channel : TInt32 = -1, # only useful if `verbose == True`
) -> TNone:
    # Index of TTL channel 58 in Artiq code:  `self.ttl58.channel == 58` (TInt32)
    # Physical locations of those TTL channels:  Kasli board's EEM{ch % 12} -> DIO_SMA board's IO{ch // 12}
    # DIO_SMA board's IO0, IO1, IO2, IO3 (upper 4 channels) are controlled by bank 0 and are all together
    # either outputs or inputs. Same for IO4, IO5, IO6, IO7 (lower 4 channels), which are controlled by bank 1.
    # We enumerate the banks from 0, 1 (Kasli board's EEM0) to 22, 23 (Kasli board's EEM11).
    # Bank index of TTL channel 58:  `bank = self.ttl58.channel // 4 == 14` (TInt32)
    # `i2c_switch0` controls Kasli board's EEM{0, 1, ..., 7}
    # `i2c_switch1` controls Kasli board's EEM{8, 9, 10, 11}
    if bank < 16:
        sw = i2c_switches[0]
    else:
        sw = i2c_switches[1]
    # We map our bank indices to actual electrical bus(?) indices that need to be passed to the FPGA:
    i2c_addr = KASLI_I2C_DIO_SMA_BANK_TO_PORT_MAPPING[bank]
    # We "enable one channel", i.e. we select one DIO_SMA board. Source: artiq/coredevice/i2c.py.
    # We have confirmed that `self.i2c_switch0` is an instance of `artiq.coredevice.i2c.I2CSwitch`
    # via `@proc def type(self, obj) -> TStr: return str(type(obj))`.
    sw.set(
        channel = i2c_addr,
    )
    # Read current directions of our DIO_SMA board:
    # 1 means TTL_IN, 0 means TTL_OUT
    directions = i2c_read_byte(
        busno   = DIO_SMA_BUS_NUMBER,
        busaddr = DIO_SMA_BUS_ADDRESS,
    )
    # We define an output_mask that is 1 for all channel that belongs to our bank:
    # output_mask 00001111 for bank even, i.e. upper 4 channels (IO0, IO1, IO2, IO3)
    # output_mask 11110000 for bank odd , i.e. lower 4 channels (IO0, IO1, IO2, IO3)
    bank_mask = ((1 << 4) - 1) << (4 * (bank % 2)) # = b1111 << {0 or 4}
    # We take `directions` and zero the bits that belong to our bank:
    new_directions = directions ^ (directions & bank_mask)
    i2c_write_byte(
        busno   = DIO_SMA_BUS_NUMBER,
        busaddr = DIO_SMA_BUS_ADDRESS,
        data    = new_directions,
    )
    # We "disable output of the I2C switch", i.e. we de-select all DIO_SMA boards. Source: artiq/coredevice/i2c.py.
    sw.unset()
    if verbose:
        if bank < 16:
            sw_nr = "0"
        else:
            sw_nr = "1"
        print(
            "channel:", prepend_zeros(channel, 2), "|",
            "bank:", prepend_zeros(bank, 2), "|",
            "i2c_addr:", i2c_addr, "|",
            "sw:", sw_nr, "|",
            "dir:", to_binary(directions), "|",
            "bank_mask:", to_binary(bank_mask), "|",
            "(new_dir) dir ^ (dir & mask):", to_binary(new_directions),
        )

@kernel
def print_dio_sma_debug_output(
    ttl_ch_list,
    i2c_switches,
) -> TNone:
    for ch in ttl_ch_list:
        # Index of TTL channel 58 in Artiq code:  `self.ttl58.channel == 58` (TInt32)
        # Physical locations of those TTL channels:  Kasli board's EEM{ch % 12} -> DIO_SMA board's IO{ch // 12}
        ch_nr = ch.channel
        # DIO_SMA board's IO0, IO1, IO2, IO3 (upper 4 channels) are controlled by bank 0 and are all together
        # either outputs or inputs. Same for IO4, IO5, IO6, IO7 (lower 4 channels), which are controlled by bank 1.
        # We enumerate the banks from 0, 1 (Kasli board's EEM0) to 22, 23 (Kasli board's EEM11).
        # Bank index of TTL channel 58:  `bank = self.ttl58.channel // 4 == 14` (TInt32)
        bank = ch_nr // 4
        set_ttl_bank_to_output(
            i2c_switches = i2c_switches,
            bank         = bank,
            verbose      = True,
            channel      = ch_nr,
        )
